30RB_S

Carrier Commercial Chillers Air Cooled chiller
30RB_S
Air Cooled Chiller with Scroll Fixed Speed Compressor

30RB_S

Carrier 30XB / 30XBP – AquaForce® Air‑Cooled Liquid Chiller
Economical and highly reliable air‑cooled screw chillers delivering 76 to 478 nominal tons (267 to 1,682 kW), engineered for high‑ambient operation, low sound levels, and efficient performance in commercial and industrial applications.

Contact Sales Contact Support

Features

Performance & Capacity

Cooling capacity range: 76 to 478 nominal tons 267 to 1,682 kW Full‑load operation at ambient temperatures from ‑20°C to 48°C No additional adiabatic systems required Performance declared and certified in accordance with: EN 14511‑3:2013 / Eurovent or AHRI 550/590 / AHRI certification

Energy Efficiency Options

30XB (AC fan motors) Economical solution for process and high‑ambient applications Average performance: SEPR 5.2 SEER 4.2 EER 3.1 30XB with variable‑speed AC fans Improved seasonal efficiency for comfort cooling Average performance: SEPR 5.5 SEER 4.3 EER 3.1 30XBP (EC fan motors – Premium version) Enhanced full‑load and part‑load efficiency Average performance: SEPR 5.9 SEER 4.4 EER 3.2 Eurovent Energy Efficiency Class A SEER (12/7°C) up to 4.6 per EN 14825

Compressor & Refrigeration Technology

Carrier 06T twin‑rotor fixed‑speed screw compressors High‑efficiency motor with variable capacity valve for precise load matching Industrial‑type construction with oversized bearings Motor cooled by suction gas Automatic compressor unloading under abnormal condensing pressure Continued operation at reduced capacity instead of shutdown

Heat Exchange & Airflow Design

Carrier flooded shell‑and‑tube evaporator New copper tube design for low pressure drops 2nd‑generation “V”‑shape Carrier Novation™ microchannel condensers Optional Enviro‑Shield coatings 6th‑generation Flying Bird™ fans AC motors for 30XB EC motors for 30XBP Inverter‑driven EC fans on 30XBP eliminate start/stop noise at part load Optional hydraulic module for sizes 250–500

Acoustic Performance

Optimized airflow paths for low operating sound levels Wide “V” coil arrangement for quieter air movement Suitable for noise‑sensitive commercial environments

Reliability & Durability

Dedicated electronic compressor protection module All compressor components easily accessible to minimize downtime High‑corrosion‑resistance Novation™ MCHE coils Optional evaporator thermal insulation with aluminum sheet finish for UV and mechanical protection Designed using advanced finite‑element stress analysis and endurance testing

Control / Integrations

Lorem ipsum dolo

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam

Lorem ipsum dolo

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam

Technical Documents

Document Name Description Document Type Language Action
30RB-S Brochure PDF English Download
