Toshiba MMD‑UP_HFP‑E / MMD‑UP_1HFP‑E – VRF Fresh Air Intake Unit
High‑capacity VRF indoor fresh air intake unit designed to treat and distribute outdoor fresh air, delivering 8.9 to 40 kW capacity with powerful airflow, quiet operation, and flexible integration into Toshiba VRF systems.

Contact Sales Contact Support

Features

Performance & Capacity

Capacity range: 8.9 to 40 kW (5 to 14 HP) Designed exclusively for fresh air intake and treatment Suitable for VRF system integration Supports centralized fresh air supply without a dedicated AHU

Airflow & Acoustic Performance

Airflow range: 1,080 to 3,060 m³/h Maximum sound level: 42 dB(A) Designed for stable and quiet operation Suitable for occupied commercial and institutional environments

AHU Alternative Design

Provides fresh air ventilation without a large air handling unit Ideal for buildings with: Limited outdoor space Defined tenant zoning Decentralized ventilation requirements Simplifies system design and reduces installation complexity

Pre‑Conditioning Functions

Pre‑heat and pre‑cool capability Discharge air temperature adjustable from 13°C to 30°C Reduces thermal load on downstream indoor units Enhances overall HVAC system efficiency

Adaptability & Installation

External static pressure available up to 200 Pa Supports flexible ducting layouts Designed for: Schools Hospitals Offices Commercial buildings requiring controlled fresh air intake Compact indoor unit format simplifies installation

Air Quality Options

Standard and high‑performance air filters available as options Supports improved indoor air quality for sensitive environments Suitable for healthcare and educational facilities

Control / Integrations

VRF System Integration

Fully compatible with Toshiba VRF systems
Uses TU2C‑LINK control connection
Enables coordinated operation with:
VRF outdoor units
Indoor units
Ventilation components

Centralized Control

Supports integration into centralized VRF control strategies
Allows unified management of fresh air intake and space conditioning
Simplifies monitoring and operation for building managers

Applications

Schools and universities
Hospitals and healthcare facilities
Office buildings
Commercial and mixed‑use developments
Projects requiring fresh air ventilation without large AHUs

Technical Documents

Document Name Description Document Type Language Action
Product Data PDF English Download
